Digifast M.2 NVMe SSD Enclosure, USB3.1 GEN2 Type-C (10 Gbps), Aluminum Digifast M.2 NVMe SSD Enclosure, USB3.1 GEN2 Type-C (10 Gbps), Aluminum
- Description
- Specification
- FAQ
 |
Travel size form factor allow you to use this alongside your laptop
All aluminum construction boasts premium built quality that ensure your M.2 SSD safely protected within. Digifast M.2 Enclosure allow you to have the confident to bring this with you anywhere!
Aluminum Machined body
Enclosure is made from aluminum giving it excellent heat dissipation, and the entire body acts as a heat sink to efficiently dissipate the heat of the NVMe M.2 SSD, which has high heat.
High Precision CNC Processing
The internals are also CNC machined with high precision so that the NVMe M.2 SSD and the base chip contact the aluminum properly.
Designed Exclusively for NVMe M.2 SSD
Supports the non-volatile memory express (NVMe) SSD, a PCI Express storage standard The connector standard adopts M.2. Compatible with all sizes of NVMe M.2 SSD. (Type 2280/2260/2242)
※ Does not support M. 2 SSD SATA protocol. ※ Does not support M.2 SSD of AHCI standard.
USB 3.1 (Gen 2) Type-C Interface
The docking bay utilizes the USB 3.1 (Gen2), Type-C interface which supports high-speed transfer rates of up to 10 Gbps.
※ USB3.1 Type-C to Type-A cable is attached to this product. When connecting to a PC with Type-C, prepare a separate USB Type-C to Type-C cable or Type-A to Type-C adapter.
Benchmark software used: ATTO Disk Benchmark
SSD used: SAMSUNG M.2 NVME SSD 960 EVO 250G
Measurement result with USB3.1 Gen2 compatible USB port
| Interface | USB 3.1 GEN 2 Type C |
| Color | Black |
| Dimensions | 102mm x 35mm x 11mm |
| OS Support | Windows® 10 Windows® 10 64-bit Windows® 8.1 Windows® 8 Mac OS X 10.6 or Above |
| Speed | 10 Gbps |
| SSD Compatibility | M.2 M Key PCIe (NVMe) SSD with 2280/2260/2242 |
**For more detail on the specs sheet please contact info@digifast-usa.com
Q1. What size M.2 does this support?
The Digifast enclosure supports NVMe M.2 of sizes 2242, 2260, and 2280. These sizes refer to the width and height in mm, ie 22mm x 42mm.
Q2. Does this device require any tools?
All tools required to use the enclosure are included with the device (except for the drive itself).
Q3. Will this device work with any operating system?
The device works with Windows 7 or later and MacOS 10.10.5 (Yosemite) or later. Most Linux distributions will work as well.
Q4. If I remove my SSD from a working PC, will I be able to read the files using this device?
Yes, so long as the drive you are removing is NVMe (as opposed to SATA), this will work without issues.
Q5. How fast will my SSD run using this enclosure?
The enclosure uses USB 3.2 Gen 2 which has a maximum transfer rate of 10 Gbps. This translates to at most 1000 MB/sec read and write.
Q6. What chip does the enclosure use?
It uses the JMicron JMS583 controller.
Q7. How long is the USB cable included?
The cable is a type-C to type-A cable and measures 20.5 cm
